Product Specification：
● Luminance Efficacy: Frosted Cover:150lm/W Clear Cover:155lm/W。
● LED Type: 2835 LED,Epistar
● Input Voltage: AC100-240V
● CCT:3000K 4000K 5000K 6000K
● Series A :Compatible with only
● Series B :Compatible with EVG,KVG(remove starter) and AC input directly
●CRI:>80
● PF:>0.95
● Beam Angle:140°(Frosted Cover)
● Service life: 30000 hours。
● Working Temperature: -20℃-48℃。
● Driver Type: Internal Driver
| Model No. | Length | Power | Lumen | Size(mm) | Carton Size(cm) | G.W/25PCS |
|---|---|---|---|---|---|---|
| SL-DGA00-418WT-G5-ET-A | 4ft | 18W | 2700lm | Ø22*L1148 | L120*W19*H12 | 12.00KG |
| SL-DGA00-418WT-G5-ET-B | 4ft | 18W | 2700lm | Ø22*L1148 | L120*W19*H12 | 12.00KG |
| SL-DGA00-525WT-G5-ET-A | 5ft | 25W | 3750lm | Ø22*L1488 | L150*W19*H12 | 14.05KG |
| SL-DGA00-525WT-G5-ET-B | 5ft | 25W | 3750lm | Ø22*L1488 | L150*W19*H12 | 14.05KG |
*Remarks: “W”means 6000K. 3000K ,4000K available, Only change“W” to “N”,“L” in Model No.
“A”means EVG, For electronic ballasts only.
“B”means Compatible with EVG, KVG (remove starter) and AC input directly
| 2feet(0.6m) | 3feet(0.9m) | 4feet(1.2m) | 5feet(1.5m) | 8feet(2.4m) | |
|---|---|---|---|---|---|
| A | 562mm | 862mm | 1162mm | 1462mm | 2362mm |
| B | 548mm | 848mm | 1148mm | 1448mm | 2348 |
IApplications
Indoor illumination at -20°~+48°C Living area illumination, Office area illumination, Production area illumination, Parking lot & hotel area illumination, Supermarket & grocery store illumination.
Benefits
6063 aluminum non-bending housing with better heat dissipation, lower light decay.
No need to cut wiring or re-wire, efficient and safe.
Energy-saving up to 70% (compared with fluorescent lamp).
Series B can bypass the ballast to work, when the ballast is damaged.
No need to repurchase the electronic ballast.
Special protection design, preventing the impact damage caused by on-off switching load.
Applicable to low temperature using Special coating to avoid aluminum exposure.
Features
Plug and play LED Tube to directly replace traditional fluorescent tube High luminous efficiency, environment friendly and energy saving, stable and durable structure Uniform illumination, no blue light harm to human eyes Installed on the traditional fluorescent lamp controlling device.
